Capabilities

FTJLSFRG1BBC8KD.LARGE_

The following table represents our minimum manufacturing specifications

PROTOTYPES MASS PRODUCTION
thou mm thou mm
Conductor Width 6 0.15 8 0.2
Conductor Spacing 6 0.15 8 0.2
Annular Ring 8 0.2 10 0.25
Hole Size 16 0.4 16 0.4

Circuit Types

  • Single sided
  • Double sided THP
  • Solder paste stencils
  • Face plates(on aluminium or FR4)
  • RF shield boxes
  • Brass etching
  • Multilayer
  • FlexIble Curcuits
  • Double-sided NTHP
  • Tufnol Jigs

Finishes

  • Hot air solder level
  • ROHS immersion silver

Minimum Manufacturing Specifications Data Format

  • Extended Gerber – RS274X
  • Extended Gerber – RS274X2
  • Standard Gerber – RS274D
  • N.B. Other formats are acceptable – please enquire
  • Netlist Data: IPC – D – 356 preferred
  • Data Transfer: E-Mail
  • Capabilities – Master Circuits

Ready to find out more?

Drop us a line today for a free quote!

Contact Us Today
